Name: JX-RT150/3*16-4 High Current Fixed Distribution Terminals
Brand: SHANGHAI GKONCY ELECTRIC CO., LTD.

JX-RT150/3*16-4 High Current Fixed Distribution Terminals

1. Wiring range: Input: 22-60mm², Output: 4-16mm²

2. Screw connection, usable globally.

3. Fence-style wiring structure, stable and reliable connection.

4. Meets cabinet and panel electrical connection requirements.

5. The number of poles can be arbitrarily combined, enabling one-in-multiple-out and multiple-in-multiple-out wiring functions to meet customer needs.

6. This series of terminals comes in two types: one that can be mounted on both DIN rails and bolts, and another that can only be mounted on DIN rails.

7. Marking strips meet the marking needs of users in different scenarios.

8. Connecting components can quickly achieve multi-digit shorting or bridging.

High current fixed distribution terminals generally refer to equipment used for power distribution and connection. Its main advantages include:

High current carrying capacity: These terminals are designed to carry high currents and are usually used in power systems where high current transmission is required, such as industrial equipment, power distribution boxes, etc.

Stable connection: Fixed distribution terminals ensure that the wire connection is stable and can operate safely for a long time, reducing the risk of failure caused by excessive current or poor connection.

Reliability: The design takes into account the requirements of high load and continuous use, ensuring long-term stable working performance and reducing the frequency of maintenance and replacement.

Technical Data		Part Number			2700269
Terminal strip dimensions		Length	Width	Height
		70	153	45
Parameters according to the IEC 60 947-7-1 standard
Isolation voltage	V	600
Rated current	A	175
Cross-sectional area for rated input / output	(mm²)	22-38/4-16
Rated impulse voltage / degree of pollution		2.5KV/3
Flammability according to the standard UL94		V0
Additional Technical Data
Short-circuit current (peak)		15KA
Short-circuit current time		>1S
Input
Number of input terminal points		1
Single-stranded rigid conductor H07V-U with round terminal	(mm²)	22..60
Stranded rigid conductor H07V-R with round terminal	(mm²)	22..60
Flexible conductor H07V-K with round terminal	(mm²)	22..60
Tightening torque	(Nm)	8-10
Screw specification for crimping		M8
Stripping length	(mm)	18
Sleeve	(mm)	13
Output
Number of output terminal points		3
"e" single-stranded rigid conductor H07V-U	(mm²)	4..16
"m" stranded rigid conductor H07V-R	(mm²)	4..16
"f" flexible conductor H07V-K	(mm²)	4..16
"f" flexible conductor H07V-R with tubular terminal according to DIN46228-1	(mm²)	4..16
"f" flexible conductor H07V-R for tubular terminal with plastic sleeve according to DIN46228-1	(mm²)	4.16
Diameter (ф)	(mm)	7
Tightening torque	(Nm)	3-4.5
Screw specification for crimping		M6
Stripping length	(mm)	10/18
Hex key		5
Accessories
Mounting guide rail		TH35-7.5 / terminal height (47 mm)			8034101
		TH35-15 / terminal height (54 mm)			8044101
End plate
Tag (width: 9.5 mm) Tag used after combination of N terminals
Dust cover (width: 58 mm)		ZP-JX-RT 2700001

		With dust cover
