JX-RT100/2*25-3 High Current Fixed Distribution Terminals

Isolation voltage

V

600

Rated current

A

130

Cross-sectional area for rated input / output

(mm²)

22-38/6-25

Rated impulse voltage / degree of pollution

2.5KV/3

Flammability according to the standard UL94

V0

Additional Technical Data

Short-circuit current (peak)

10KA

Short-circuit current time

>1S

Input

Number of input terminal points

1

Single-stranded rigid conductor H07V-U with round terminal

(mm²)

22..38

Stranded rigid conductor H07V-R with round terminal

(mm²)

22..38

Flexible conductor H07V-K with round terminal

(mm²)

22..38

Tightening torque

(Nm)

8-10

Screw specification for crimping

M8

Stripping length

(mm)

14

Sleeve

(mm)

13

Output

Number of output terminal points

2

"e" single-stranded rigid conductor H07V-U

(mm²)

6..25

"m" stranded rigid conductor H07V-R

(mm²)

6..25

"f" flexible conductor H07V-K

(mm²)

6..25

"f" flexible conductor H07V-R with tubular terminal according to DIN46228-1

(mm²)

6..25

"f" flexible conductor H07V-R for tubular terminal with plastic sleeve according to DIN46228-1

(mm²)

6.25

Diameter (ф)

(mm)

8.6

Tightening torque

(Nm)

6-9

Screw specification for crimping

M8

Stripping length

(mm)

12

Hex key

6

Accessories

Mounting guide rail

TH35-7.5 / terminal height (47 mm)  8034101

TH35-15 / terminal height (54mm)  8044101

End plate

JX-RT100A-G 910480

Tag (width: 9.5 mm)

Tag used after combination of N terminals

Dust cover (width: 58 mm)

ZP-JX-RT 2700001

With dust cover
