ZP10 Quick Marking Strip

Quick tag, blank:

10 digits / each tag; the maker pen M-PEN, ZBF-T or CMS system can also be used for identification; suitable for 100 terminals

ZP10: blank

Quick tag, horizontal writing, ²⁾, 10 digits, consecutive numbers

1-10

11-20

To

91-99

ZP10.LGS: continuous numbers

ZP10.LGS: 1-10

ZP10.LGS: 11-20

To

ZP10.LGS: 991-1000

Quick tag, horizontal writing, ²⁾, 10 digits, same number

1/1/1

2/2/2

To

1000/1000/1000

ZP10.LGS: same number

ZP10.LGS: 1

ZP10.LGS: 2

To

ZP10.LGS: 1000

Quick tag, horizontal writing, ²⁾, 10 digits

L1, L2, L3, N, PE
U, V, W, NŒ

ZP10, LGS: L1-N, PE

ZP10, LGS: U-N

Quick tag, vertical writing ²⁾, 10 digits, same number

1-10

11-20

To

991-1000

ZP10.RQ: Continuous numbers

ZP10.RQ: 1-10

ZP10.RQ: 11-20

To

ZP10.RQ: 991-1000

Quick tag, vertical writing ²⁾, 10 digits, same number

1/1/1

2/2/2

To

1000/1000/1000

Quick tag for special characters:

10 digits that can be divided; identification upon the customer's request

ZP10.: SO/CMS…¹⁾

Material

PA

Material flammability according to UL94

V2

Temperature range

- 40 °C to +100 °C

Color

White

Scrape abrasion resistance

DIN EN61010-1 VDE0411.1

Components

Free of silicon and halogen elements

1) Please specify any required marks and colors in the order.

2) Each packing unit (PU) contains 10 tags of the same type. Marks can be printed with the CMS system.

Order example: standard tag

The terminal thickness is 10.2 mm. Horizontal writing is required. There are 100 tags with the same number "12".

Quantity: 100

Part Number: 8868405

Description: ZP10, LGS: horizontal; same number "1/2"
