Name: JWD2-6NZ/S Push-in Switching Test Din-Rail TB
Brand: SHANGHAI GKONCY ELECTRIC CO., LTD.

JWD2-6NZ/S Push-in Switching Test Din-Rail TB

−Only two JWD2-6NZ/S can be used to create a current transformer circuit.
−Less space is required than that for creating a circuit with sliding terminal for breaking capacity.
① FBS...plug-in bridgeware for cross-connection
② 4 mm (diameter) GPAI-4-FIX...test socket
③ GS-ME 6 switch lock
④ SB-ME...bridgeware
⑤ GC-ME 6/2 toggle switch operating lever

Terminal thickness		8.2
Overall dimensions
Width / thickness / height (mm)	96.9/8.2/(55.9/63.4)
Stripping length (mm)	10-12mm
Rating data
Rated voltage / rated current / rated cross-section	1000V/32A/6mm²
Rated impulse withstand voltage / degree of pollution	8kV/3
Central liaison unit Imax	41A
Conductor clamping range (mm²)
Single conductor	1 10
Stranded conductor (with tubular pre-insulated terminal)	0.5 6

Order Data
Description	Position No.	Color	Type
Test adapter used for the 4 mm (diameter) safety test plug and clamped to the bridge	1	Orange	PAI-4-FIX OG
	1	Yellow	PAI-4-FIX YE
	1	Green	PAI-4-FIX GN
	1	Purple	PAI-4-FIX VT
	1	Black	PAI-4-FIX BK
	1	Blue	PAI-4-FIX BU
	1	Red	PAI-4-FIX RD
	1	Grey	PAI-4-FIX GY
	1	Brown	PAI-4-FIX BN
	1	White	PAI-4-FIX WH
Switch lock, pluggable		White	S-ME6
Switch bridgeware, pluggable	2	Grey / orange	SB-ME 2-8
	3	Grey / orange	SB-ME 3-8
	4	Grey / orange	SB-ME 4-8
Operating lever used to drive the test terminal for breaking capacity	1	Orange	C-ME 6/1
	2	Orange	C-ME 6/2
	3	Orange	C-ME 6/3

Order Data		Color	Type
		Grey	JWD2-6NZ/S
		Blue	JWD2-6NZ/S BU
Partition
Thickness = 2.2 mm		Grey	G-D2-6NZ/S
		Blue	G-D2-6NZ/S BU
Group partition
Thickness = 2 mm		Grey	GF-D2-6NZ/S
Plug-in bridgeware
		2 channels	FBS2-8
		3 channels	FBS3-8
		4 channels	FBS4-8
		5 channels	FBS5-8
		10 channels	FBS10-8
Test plug
			CPS6T
Conversion test jack

Holder
	Thickness: 10mm		ZG4
Screwdriver
	Dimensions (Thickness X Width)		SZF 1-0.6X3.5
Marking number
		Blank	ZP8
Marking number
		Blank	ZBFM8
